Ring Mode (ISDN MSN Last No. 0 or 00)
Selects the ring mode when receiving an incoming call with an MSN ending with "0" or "00".
Value Range
Ring All Extension for MSN: Ring all ISDN extensions that are addressed with MSN.
Ring AN Extension for MSN: Ring only one of the ISDN extensions that are addressed with MSN.
Maintenance Console Location
9.26 PBX Configuration—[1-1] Configuration—Slot—Port Property - PRI Port
Feature Guide References
5.2.5.1 ISDN Extension
Network Configuration
The Shelf, Slot, and Port for each item are displayed for your reference. For details, see Common
Programming Reference Items in 9.1 PBX Configuration—[1-1] Configuration—Slot.
Port Type
Selects the port type.
Note
• Each ISDN connection in a QSIG network must have a master port on one PBX and a slave port on
another PBX.
• ISDN extensions can belong to an incoming call distribution group or idle extension hunting group. In
this case, an MSN can be assigned.
Value Range
CO: For connecting to public network
Extension: For connecting to extension
QSIG-Slave: For connecting to private network (slave port)
QSIG-Master: For connecting to private network (master port)
Maintenance Console Location
9.26 PBX Configuration—[1-1] Configuration—Slot—Port Property - PRI Port
Connection
Indicates the port status. To change the status of the port, click the desired cell in the column, and then select
INS or OUS for the port.
This option is only available in On-line mode.
Value Range
INS: The port is in service.
OUS: The port is out of service.
Fault: The port is not communicating with the network.
384 PC Programming Manual
9.26 PBX Configuration—[1-1] Configuration—Slot—Port Property - PRI Port
