9.11.2 PBX Configuration—[1-1]
Configuration—Slot—V-IPGW—Shelf Property—Hunt Pattern
The related settings of hunt patterns can be programmed. The hunt pattern determines how to route incoming
calls through virtual IP trunks to the PBX.
A maximum of 32 hunt patterns can be programmed.
Hunt Pattern 1–16
Leading Number
Specifies the leading digits of dialled numbers by which to determine the call distribution port group to direct
incoming calls.
Value Range
Max. 30 digits (consisting of 0–9)
Maintenance Console Location
9.11.2 PBX Configuration—[1-1] Configuration—Slot—V-IPGW—Shelf Property—Hunt Pattern
Call Distribution Port Group—1st–16th
Specifies the number of the call distribution port group to which incoming calls are directed in priority.
Value Range
For 1st:
CDPG1–CDPG48
For 2nd–16th:
None, CDPG1–CDPG48
Maintenance Console Location
9.11.2 PBX Configuration—[1-1] Configuration—Slot—V-IPGW—Shelf Property—Hunt Pattern
PC Programming Manual References
9.12 PBX Configuration—[1-1] Configuration—Slot—V-IPGW—Port Property—
Call Distribution Port Group
Feature Guide References
4.2.2.3 Call Distribution Port Group
PC Programming Manual 295
9.11.2 PBX Configuration—[1-1] Configuration—Slot—V-IPGW—Shelf Property—Hunt Pattern

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
