Panasonic KX-NS500 Pc Programming Manual

9.28 PBX Configuration—[1-1]
Configuration—Slot—Card Property—E1 type Line
Signal Setting
DR2 Setting Type
Selects the control type of the DR2 (Digital System R2) signal.
Value Range
Normal, Option 1, Option 3
Maintenance Console Location
9.28 PBX Configuration—[1-1] Configuration—Slot—Card Property—E1 type Line Signal Setting
Inter-digit Timer
Specifies the pseudo-answer time. This setting is available only when Option 1 or Option 3 is selected in DR2
Setting Type on this screen..
Value Range
3-15
Maintenance Console Location
9.28 PBX Configuration—[1-1] Configuration—Slot—Card Property—E1 type Line Signal Setting
Bit Position for Dial Pulse
Selects the position of the pulse dial control bit in a DR2 signal.
Value Range
A-bit, B-bit
Maintenance Console Location
9.28 PBX Configuration—[1-1] Configuration—Slot—Card Property—E1 type Line Signal Setting
Bit Position for Clear Back
Selects the position of the clear-back signal control bit in a DR2 signal.
Value Range
A-bit, B-bit, A&B-bit
Maintenance Console Location
9.28 PBX Configuration—[1-1] Configuration—Slot—Card Property—E1 type Line Signal Setting
PC Programming Manual 393
9.28 PBX Configuration—[1-1] Configuration—Slot—Card Property—E1 type Line Signal Setting

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
