9.13 PBX Configuration—[1-1]
Configuration—Slot—V-IPEXT—Card Property
The properties of the V-IPEXT card can be specified.
Signalling (PTAP) UDP Port No. (Server)
Specifies the UDP port used by the V-IPEXT card to transmit and receive PTAP (Panasonic Telephony
Administration Protocol) data. This must be changed if another network application is using the same port.
To change the value displayed here, click Common Settings and set the desired value.
Value Range
1024–65535
Maintenance Console Location
9.13 PBX Configuration—[1-1] Configuration—Slot—V-IPEXT—Card Property
Feature Guide References
5.2.1 IP Proprietary Telephone (IP-PT)
Signalling (MGCP) UDP Port No. (Server)
Specifies the UDP port used by the V-IPEXT card to transmit and receive MGCP (Media Gateway Control
Protocol) data. This must be changed if another network application is using the same port.
To change the value displayed here, click Common Settings and set the desired value.
Value Range
1024–65535
Maintenance Console Location
9.13 PBX Configuration—[1-1] Configuration—Slot—V-IPEXT—Card Property
Feature Guide References
5.2.1 IP Proprietary Telephone (IP-PT)
Signalling (MGCP) UDP Port No. (IP-PT)
Indicates the UDP port used to transmit and receive MGCP (Media Gateway Control Protocol) data on the
IP-PT side (reference only).
Value Range
2427
Maintenance Console Location
9.13 PBX Configuration—[1-1] Configuration—Slot—V-IPEXT—Card Property
298 PC Programming Manual
9.13 PBX Configuration—[1-1] Configuration—Slot—V-IPEXT—Card Property

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
