9.21 PBX Configuration—[1-1]
Configuration—Slot—Extension—Card Property
The property for the extension cards can be specified.
SLT Pulse Dial Mode
Selects the type of pulse dial transmission appropriate to your area.
Value Range
Normal, Sweden, New Zealand
Maintenance Console Location
9.21 PBX Configuration—[1-1] Configuration—Slot—Extension—Card Property
SLT Off Hook Time
Specifies the minimum length that a pulse dial sent from an SLT must be for the PBX to recognise it as an
off-hook signal.
Value Range
8 ´ n (n=3–255) ms
Maintenance Console Location
9.21 PBX Configuration—[1-1] Configuration—Slot—Extension—Card Property
SLT Off Hook Guard Time
Specifies the length of guard time used for off-hook signals from SLTs, to prevent the PBX mistaking them for
pulse dials.
Value Range
8 ´ n (n=12–63) ms
Maintenance Console Location
9.21 PBX Configuration—[1-1] Configuration—Slot—Extension—Card Property
SLT Pulse Maximum Break Width
Specifies the maximum length of the break signal in a pulse dial.
Value Range
8 ´ n (n=9–20) ms
Maintenance Console Location
9.21 PBX Configuration—[1-1] Configuration—Slot—Extension—Card Property
PC Programming Manual 349
9.21 PBX Configuration—[1-1] Configuration—Slot—Extension—Card Property

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
