10.8.2 PBX Configuration—[2-8-2] System—Ring Tone
Patterns—Call from DOORPHONE
Different ring tone patterns can be selected for incoming doorphone calls depending on the doorphone port
that the calls originate from. A maximum of 8 Ring Tone Pattern Tables can be programmed, and any pattern
table can be selected for use by an extension.
Ring Tone Pattern Plan 1–8
Specifies the ring tone pattern for incoming doorphone calls.
Value Range
Single, Double, Triple, S-Double, Option 1, Option 2
Maintenance Console Location
10.8.2 PBX Configuration—[2-8-2] System—Ring Tone Patterns—Call from DOORPHONE
PC Programming Manual References
12.1.1 PBX Configuration—[4-1-1] Extension—Wired Extension—Extension Settings—Option 1— Ring
Pattern Table
12.2.1 PBX Configuration—[4-2-1] Extension—Portable Station—Extension Settings—Option 1— Ring
Pattern Table
13.1 PBX Configuration—[5-1] Optional Device—Doorphone
Feature Guide References
2.1.3.2 Ring Tone Pattern Selection
2.18.1 Doorphone Call
PC Programming Manual 513
10.8.2 PBX Configuration—[2-8-2] System—Ring Tone Patterns—Call from DOORPHONE

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
