9.14 PBX Configuration—[1-1]
Configuration—Slot—V-IPEXT—Port Property
Various settings can be programmed for each virtual IP extension port.
IP-PT Registration and De-registration
An IP-PT must be registered to the PBX by programming the PBX and IP-PT before it can be used.
Programming instructions for the PBX are given below.
It is possible to de-register the IP-PT later.
IP-PT Registration, De-registration, and Forced De-registration can be performed only in On-line mode.
Preparation
Open 27.1 Network Service—[1] IP Address/Ports—Basic Settings, and confirm that the IP addresses of
the mother board and DSP card, subnet mask address, and default gateway address are set.
Registration
Follow the steps below to register the IP-PT.
1. Connect the IP-PT to be registered to the network and, if necessary, the power supply.
2. Click Registration.
A dialogue box will appear. Non-registered (available) extension numbers and names are displayed on the
left.
3. Highlight numbers and names and click the right arrow to select them for registration. Click Next.
4. Click Next.
5. If the registration is still in progress, the dialogue box will show "Registration Executing".
If the registration is successful, the dialogue box will show "Registration Completed". Click Close.
Once the IP-PT is successfully registered, the status of the IP-PT will update to show "Registered".
De-registration
Follow the steps below to de-register the IP-PT.
1. Click De-registration.
A dialogue box will appear. Registered extension numbers and names are displayed on the left.
2. Highlight numbers and names and click the right arrow to select them for de-registration. Click Next.
A dialogue box will appear.
3. Click Confirm.
If the de-registration is successful, the dialogue box will show "De-registration Succeed".
4. Click Close.
Once the IP-PT is successfully de-registered, the status of the IP-PT will update to show "None".
Forced De-registration
Follow the steps below to forcibly de-register the IP-PT when normal de-registration has been unsuccessful
or IP address settings have been changed or deleted only on the IP-PT.
1. Click Forced De-registration.
A dialogue box will appear. Registered extension numbers and names are displayed on the left.
PC Programming Manual 303
9.14 PBX Configuration—[1-1] Configuration—Slot—V-IPEXT—Port Property
