Panasonic KX-NS500 Pc Programming Manual

Transfer to CO
Enables the transferring of calls to trunks.
Value Range
Disable, Enable
Maintenance Console Location
10.7.1 PBX Configuration—[2-7-1] System—Class of Service—COS Settings
PC Programming Manual References
12.1.1 PBX Configuration—[4-1-1] Extension—Wired Extension—Extension Settings—Main— COS
12.2.1 PBX Configuration—[4-2-1] Extension—Portable Station—Extension Settings—Main— COS
Feature Guide References
2.12.1 Call Transfer
Call Forward to CO
Enables the forwarding of calls to trunks.
Value Range
Disable, Enable
Maintenance Console Location
10.7.1 PBX Configuration—[2-7-1] System—Class of Service—COS Settings
PC Programming Manual References
12.1.1 PBX Configuration—[4-1-1] Extension—Wired Extension—Extension Settings—Main—
COS
12.1.2 PBX Configuration—[4-1-2] Extension—Wired Extension—FWD/DND
12.2.1 PBX Configuration—[4-2-1] Extension—Portable Station—Extension Settings—Main— COS
12.2.2 PBX Configuration—[4-2-2] Extension—Portable Station—FWD/DND
Feature Guide References
2.3.2 Call Forwarding (FWD)
Account Code Mode
Specifies whether the entry of an account code is optional or mandatory when making a trunk call.
Value Range
Option, Forced
Maintenance Console Location
10.7.1 PBX Configuration—[2-7-1] System—Class of Service—COS Settings
496 PC Programming Manual
10.7.1 PBX Configuration—[2-7-1] System—Class of Service—COS Settings

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
