Panasonic KX-NS500 Pc Programming Manual

12.2.5 PBX Configuration—[4-2-5] Extension—Portable
Station—CLIP ID Table
Up to 8 CLIP IDs can be set for each wireless extension.
Extension Number
Indicates the extension number of the PS (reference only).
Value Range
Max. 5 digits (consisting of 0–9)
Maintenance Console Location
12.2.5 PBX Configuration—[4-2-5] Extension—Portable Station—CLIP ID Table
Extension Name
Indicates the name of the PS (reference only).
Value Range
Max. 20 characters
Maintenance Console Location
12.2.5 PBX Configuration—[4-2-5] Extension—Portable Station—CLIP ID Table
CLIP 1–8
Specifies up to 8 CLIP IDs for the PS.
Value Range
Max. 16 digits (consisting of 0–9, *, and #)
Maintenance Console Location
12.2.5 PBX Configuration—[4-2-5] Extension—Portable Station—CLIP ID Table
722 PC Programming Manual
12.2.5 PBX Configuration—[4-2-5] Extension—Portable Station—CLIP ID Table

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
