Panasonic KX-NS500 Pc Programming Manual

27.3.3 Network Service—[3-3] Client Feature—SNMP Agent
Using SNMP (Simple Network Management Protocol), it is possible for a PC assigned as an SNMP manager
to manage and receive PBX system status information, such as alarm information and general system activity.
The related PBX system settings can be programmed.
This option is only available at Installer level.
SNMP agent
Enables the PBX to use its SNMP agent function.
Value Range
Disable, Enable
Maintenance Console Location
27.3.3 Network Service—[3-3] Client Feature—SNMP Agent
Feature Guide References
2.4.4 Simple Network Management Protocol (SNMP) System Monitor
SNMP version
Specifies the version of the SNMP protocol to use.
Value Range
SNMP V1, SNMP V2c
Maintenance Console Location
27.3.3 Network Service—[3-3] Client Feature—SNMP Agent
Feature Guide References
2.4.4 Simple Network Management Protocol (SNMP) System Monitor
SNMP manager port
Specifies the SNMP manager port.
Value Range
161, 1024–65535
Maintenance Console Location
27.3.3 Network Service—[3-3] Client Feature—SNMP Agent
Feature Guide References
2.4.4 Simple Network Management Protocol (SNMP) System Monitor
1000 PC Programming Manual
27.3.3 Network Service—[3-3] Client Feature—SNMP Agent

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
