9.25 PBX Configuration—[1-1]
Configuration—Slot—Card Property - PRI type
The properties of the PRI card can be specified.
ISDN CO / QSIG Master / QSIG Slave—T200
Specifies the maximum time that the PBX waits for a reply after sending the L2 command to ISDN.
Value Range
0–600 ´ 100 ms
Maintenance Console Location
9.25 PBX Configuration—[1-1] Configuration—Slot—Card Property - PRI type
ISDN CO / QSIG Master / QSIG Slave—T202
Specifies the maximum time that the PBX waits for a reply after resending the request to use an ISDN line as
a TIE line.
Value Range
0–600 ´ 100 ms
Maintenance Console Location
9.25 PBX Configuration—[1-1] Configuration—Slot—Card Property - PRI type
Feature Guide References
4.2.1 TIE Line Service
ISDN CO / QSIG Master / QSIG Slave—T203
Specifies the length of time to detect no communication status of L2.
Value Range
0–600 ´ 100 ms
Maintenance Console Location
9.25 PBX Configuration—[1-1] Configuration—Slot—Card Property - PRI type
ISDN CO / QSIG Master / QSIG Slave—T301
Specifies the maximum time that the PBX waits for a reply after making a call to ISDN.
Value Range
0–18000 ´ 100 ms
370 PC Programming Manual
9.25 PBX Configuration—[1-1] Configuration—Slot—Card Property - PRI type

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
