10.11.2 PBX Configuration—[2-11-2] System—Audio Gain—Card
Gain levels can be programmed for each type of card.
Up Gain (To PBX)
Specifies the volume for audio signals from the selected type of card to the PBX.
Value Range
-31.5–31.5 dB
Maintenance Console Location
10.11.2 PBX Configuration—[2-11-2] System—Audio Gain—Card
Down Gain (From PBX)
Specifies the volume for audio signals from the PBX to the selected type of card.
Value Range
-15.5–15.5 dB
Maintenance Console Location
10.11.2 PBX Configuration—[2-11-2] System—Audio Gain—Card
PC Programming Manual 551
10.11.2 PBX Configuration—[2-11-2] System—Audio Gain—Card

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
