Panasonic KX-NS500 Pc Programming Manual

PC Programming Manual References
13.1 PBX Configuration—[5-1] Optional Device—Doorphone
Feature Guide References
2.18.1 Doorphone Call
Group Paging
Specifies the feature number used to page a certain paging group.
Value Range
Max. 4 digits (consisting of 0–9, *, and #)
Maintenance Console Location
10.6.1 PBX Configuration—[2-6-1] System—Numbering Plan—Main
PC Programming Manual References
11.4 PBX Configuration—[3-4] Group—Paging Group
Feature Guide References
2.17.1 Paging
External BGM On / Off
Specifies the feature number, available for manager extensions, used to turn on or off the external BGM.
Value Range
Max. 4 digits (consisting of 0–9, *, and #)
Maintenance Console Location
10.6.1 PBX Configuration—[2-6-1] System—Numbering Plan—Main
PC Programming Manual References
10.2 PBX Configuration—[2-2] System—Operator & BGM
10.7.1 PBX Configuration—[2-7-1] System—Class of Service—COS Settings—Manager—
Manager
Feature Guide References
2.30.1 Background Music (BGM)
OGM Record / Clear / Playback
Specifies the feature number, available for manager extensions, used to record, clear, or play back a certain
OGM.
464 PC Programming Manual
10.6.1 PBX Configuration—[2-6-1] System—Numbering Plan—Main

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
