415–418 paper jams
415–418 paper jam messages
Error
code
Description Action
415.13 The bin 1 diverter plunger did not reach
the sensor (OE diverter plunger) on time.
See
“Mailbox diverter drive jam service check” on
page 206.
415.15 The bin 1 diverter plunger did not clear the
sensor (OE diverter plunger) on time.
415.23 The bin 2 diverter plunger did not reach
the sensor (OE diverter plunger) on time.
415.25 The bin 2 diverter plunger did not clear
the sensor (OE diverter plunger) on time.
415.33 The bin 3 diverter plunger did not reach
the sensor (OE diverter plunger) on time.
415.35 The bin 3 diverter plunger did not clear
the sensor (OE diverter plunger) on time.
416.52 The bin 1 motor (mailbox transport) did not
ramp up to the required level.
See
“Mailbox transport drive jam service check” on
page 208.
416.53 The bin 1 motor (mailbox transport)
stalled.
416.54 The bin 1 motor (mailbox transport) ran too
slow.
416.55 The bin 1 motor (mailbox transport) ran too
fast.
416.62 The bin 2 motor (mailbox transport) did
not ramp up to the required level.
416.63 The bin 2 motor (mailbox transport)
stalled.
416.64 The bin 2 motor (mailbox transport) ran
too slow.
416.65 The bin 2 motor (mailbox transport) ran
too fast.
416.72 The bin 3 motor (mailbox transport) did
not ramp up to the required level.
See
“Mailbox transport drive jam service check” on
page 208.
416.73 The bin 3 motor (mailbox transport)
stalled.
416.74 The bin 3 motor (mailbox transport) ran
too slow.
416.75 The bin 3 motor (mailbox transport) ran
too fast.
4064
Diagnostics and troubleshooting
204
