SF exit section
1 Exit rollers
2 Motor (staple finisher transport)
The exit rollers receive the paper from the entrance rollers, and then eject the paper to the compiler section.
Paper is stacked on the tamper tray in preparation for stapling.
The motor (SF transport) drives both exit and entrance rollers. See
“SF feed section” on page 916.
4064
Theory of operation
917
