SHPF left staple jam service check
Action Yes No
Step 1
Make sure that all the optional bins are properly installed.
Does the problem remain?
Go to step 2. The problem is
solved.
Step 2
Clean all the optional bin doors, and then check the paper path
and bins for paper fragments and partially fed paper.
Is the paper path free of paper fragments and partially fed paper?
Go to step 4. Go to step 3.
Step 3
Remove the paper fragments and partially fed paper.
Does the problem remain?
Go to step 4. The problem is
solved.
Step 4
Clear the optional bin paper path rollers of any dirt and
contamination.
Does the problem remain?
Go to step 5. The problem is
solved.
Step 5
a Enter the Diagnostics menu, and then navigate to:
Output bin quick feed > Feed to all bins
b To uc h Single or Continuous.
Does the problem remain?
Go to step 6. The problem is
solved.
Step 6
a Enter the Diagnostics menu, and then navigate to:
Output device adjustments > Staple test
b Select the staple job for the left staple unit.
Does the finisher staple?
Go to step 13. Go to step 7.
Step 7
a Remove the SHPF left cover. See “Staple, hole punch finisher
left cover removal” on page 699.
b Make sure that the SHPF staple cartridge door close limit switch
is properly installed. Reseat the cable on the SHPF controller
board.
Does the problem remain?
Go to step 8. The problem is
solved.
Step 8
Check the limit switch and its connector pins for damage.
Are the limit switch and its connectors free of damage?
Go to step 10. Go to step 9.
4064
Diagnostics and troubleshooting
270
