Staple finisher bin link assembly removal
Left link removal
1
Remove the staple
finisher
left cover. See “Staple
finisher
left cover removal” on page 584.
2 Unhook the spring (A), and then release the link.
A
3 Remove the three screws (B), and then release the controller board. Move the board to access the link
behind it.
4064
Parts removal
614
