4 Remove the two E-clips (B), and then remove the gears.
Staple, hole punch finisher elevator drive removal
1 Remove the staple, hole punch
finisher
left cover. See “Staple, hole punch
finisher
left cover removal” on
page 699.
2 Remove the controller board. See “Staple, hole punch finisher controller board removal” on page 705.
4064
Parts removal
722
