2100‑sheet tray transport drive
1 Pick roller
2 Aligner roller
3 Motor (transport)
Paper that is picked is received by the aligner roller, and then passed on to the transport roller of the standard
tray or optional tray (see
“Lower transport drive” on page 874). The motor (transport) drives the aligner roller.
4064
Theory of operation
890
