Sensor (hole punch) removal
1 Remove the staple, hole punch
finisher
right cover. See “Staple, hole punch
finisher
controller board
removal” on page 705.
2 Disconnect the cable (A), and then remove the sensor retainer (B).
3 Remove the sensor.
4064
Parts removal
725
