Lexmark MS825 Service Manual

Bin full sensor cover removal
1 Remove the top cover. See “Top cover removal” on page 455.
2 Remove the screw (A), and then remove the cover.
Sensor (standard bin full) removal
1 Remove the top cover. See “Top cover removal” on page 455.
2 Remove the bin full sensor cover. See “Bin full sensor cover removal” on page 460.
4064
Parts removal
460
