Staple finisher controller board removal
1 Remove the staple
finisher
left cover. See “Staple
finisher
left cover removal” on page 584.
2 Disconnect all the cables from the controller board, and then remove the three screws (A).
3 Remove the board.
4064
Parts removal
590
