13 Connect the HP oil pump 94931 to the thrust device (004).
14 Operate the HP oil pump until oil that has no air flows out at the vent screw (007).
15 Stop the HP oil pump to prevent injury.
16 Carefully close the vent screw (007).
17 Slowly increase the pressure to 1500 bar.
18 Manually tighten the screw (008).
19 Open the relief valve on the HP oil pump to release the pressure to zero.
20 Remove the HP hose from the thrust device (004).
Fig 6-3 Thrust device
00613
001
002
004003
002
008
006
006
005
Copper paste
007
21 Attach the shackle 94019G (001, Figure 6-4) to the platform.
22 Attach the chain block (004) to the shackle 94019G (001) and the lug (002).
23 Operate the chain block (004) to lift the bearing cover (001).
X72DF
AA00-1132-00AAA-520A-A
Maintenance Manual Main bearing - remove the cover
Winterthur Gas & Diesel Ltd.
- 106 - Issue 002 2020-10
