7.9.4 Exhaust valve - do a check of the seat
Periodicity
Description
One Time - after first working hours 18 000
Working hours 36 000
Duration for performing preliminary requirements 0.0 man-hours
Duration for performing the procedure 0.5 man-hours
Duration for performing the requirements after job completion 0.0 man-hours
Personnel
Description Specialization QTY
Engine crew Basic AR
Support equipment
Description Part No. CSN QTY
Eye bolt 94045-M16 1
Hammer N/A 1
Feeler gauge 94122 1
Wooden block N/A 1
Rope N/A 1
Supplies
Description QTY
Engineer’s blue paste A/R
Spare Parts
Description Part No. CSN QTY
None
SAFETY PRECAUTIONS
• None
PRELIMINARY OPERATIONS
• The exhaust valve must be disassembled, refer to section 7.9.2 Exhaust valve -
disassemble
• The valve seat must be removed.
X72DF
AA00-2751-01AAA-360A-A
Maintenance Manual Exhaust valve - do a check of the seat
Winterthur Gas & Diesel Ltd.
- 304 - Issue 002 2020-10
