7.2.2 Lubricating quill - do a functional test
Periodicity
Description
Unscheduled at each piston removal
Duration for performing preliminary requirements 0.0 man-hours
Duration for performing the procedure 0.25 man-hours
Duration for performing the requirements after job completion 0.0 man-hours
Personnel
Description Specialization QTY
Engine crew Basic 1
Support equipment
Description Part No. CSN QTY
HP oil pump 94931 1
Distributing piece 94934 1
Pressure gauge 94934A 1
Connection nipple 94934I 1
HP hose 94935 1
Supplies
Description QTY
None
Spare Parts
Description Part No. CSN QTY
None
SAFETY PRECAUTIONS
WARNING
Injury Hazard: Hydraulic tools can cause injury to personnel. Always put on gloves, a
face shield and safety goggles when you do work with hydraulic tools.
PRELIMINARY OPERATIONS
• The lubricating quill must be removed, refer to section 7.2.1 Lubricating quill - remove
• During this procedure, use oil SAE50 at 40°C (approximately 200 cSt) or SAE30 at 25°C
(approximately 190 cSt).
• During this procedure, contamination of the non-return valve with dirty or metal chips
must be prevented.
X72DF
AA00-2138-00AAA-340A-A
Maintenance Manual Lubricating quill - do a functional test
Winterthur Gas & Diesel Ltd.
- 196 - Issue 002 2020-10
