13.3.7 HP fuel pipe (fuel pump to fuel rail) - grind the sealing face
Periodicity
Description
Unscheduled
Duration for performing preliminary requirements 0.0 man-hours
Duration for performing the procedure 0.5 man-hours
Duration for performing the requirements after job completion 0.0 man-hours
Personnel
Description Specialization QTY
Engine crew Intermediate 1
Support equipment
Description Part No. CSN QTY
Grinding tool 94870F 1
Screw-on sleeve 94870E 1
Hexagon nut 94870G 1
Stencil 94870H 1
Hand drill NA 1
Supplies
Description QTY
Emery cloth AR
Polishing cloth AR
Spare Parts
Description Part No. CSN QTY
None
SAFETY PRECAUTIONS
• None
PRELIMINARY OPERATIONS
• The HP fuel pipes must be removed, refer to section 13.3.6 HP fuel pipe (fuel pump to
fuel rail) - remove
X72DF
AA00-8752-00AAA-655A-A
Maintenance Manual HP fuel pipe (fuel pump to fuel rail) - grind the sealing face
Winterthur Gas & Diesel Ltd.
- 760 - Issue 002 2020-10
