7.4.3 Piston rod gland - install
Periodicity
Description
Unscheduled at each piston removal
Duration for performing preliminary requirements 0.0 man-hours
Duration for performing the procedure 1.0 man-hours
Duration for performing the requirements after job completion 0.0 man-hours
Personnel
Description Specialization QTY
Engine crew Basic AR
Support equipment
Description Part No. CSN QTY
Assembly tool 94233 1
2- part clamp ring 94231A, 1
Distance piece 12 mm 94231B 1
Distance piece 11 mm 94231C 1
Distance piece 9 mm 94231D. 1
Template 94231E 1
Supplies
Description QTY
None
Spare Parts
Description Part No. CSN QTY
Scraper ring 4-part 1
Scraper ring 4-part (with
dowel pin)
1
Gasket 4-part 1
Gasket 4-part 1
Gasket 4-part 2
Ring support 4
Scraper ring 3-part 8
Spring 4
Spring 4
O-ring 2
SAFETY PRECAUTIONS
• None
X72DF
AA00-2303-00AAA-720A-A
Maintenance Manual Piston rod gland - install
Winterthur Gas & Diesel Ltd.
- 230 - Issue 002 2020-10
