7.1.7 Cylinder liner - install
Periodicity
Description
Unscheduled As necessary
Duration for performing preliminary requirements 0.0 man-hours
Duration for performing the procedure 2.0 man-hours
Duration for performing the requirements after job completion 0.0 man-hours
Personnel
Description Specialization QTY
Engine crew Basic AR
Support equipment
Description Part No. CSN QTY
Shackle 94019L 3
Shackle 94019H 3
Lifting tool 94201 1
Assembly tool 94233 1
Lever chain hoist 94016-003 3
Eye bolt 94045-Mxx 3
Chain 94202A 1
Supplies
Description QTY
Oil A/R
Non-hardening sealing compound (for example Hylomar Universal Blue) A/R
Copper paste A/R
Spare Parts
Description Part No. CSN QTY
Cylinder liner 1
O-ring 4
O-ring 2
O-ring 1
O-ring 1
SAFETY PRECAUTIONS
• None
PRELIMINARY OPERATIONS
• None
X72DF
AA00-2124-00AAA-720A-A
Maintenance Manual Cylinder liner - install
Winterthur Gas & Diesel Ltd.
- 188 - Issue 002 2020-10
To Next Page
General
