7.9.3 Exhaust valve - remove the seat (with new tool)
Periodicity
Description
One Time - after first working hours 18 000
Working hours 36 000
Duration for performing preliminary requirements 0.0 man-hours
Duration for performing the procedure 1.0 man-hours
Duration for performing the requirements after job completion 0.0 man-hours
Personnel
Description Specialization QTY
Engine crew Basic AR
Support equipment
Description Part No. CSN QTY
Assembly tool TN 94114 1
Valve seat dismantling
device
TN 94115 1
Wooden support N/A 1
Supplies
Description QTY
None
Spare Parts
Description Part No. CSN QTY
None
SAFETY PRECAUTIONS
CAUTION
TO PREVENT INJURY, USE ONLY APPLICABLE LIFTING EQUIPMENT TO LIFT AND MOVE
THE VALVE CAGE.
PRELIMINARY OPERATIONS
• The exhaust valve must be removed, refer to section 7.9.1 Exhaust valve - remove
X72DF
AA00-2751-01AAA-520C-A
Maintenance Manual Exhaust valve - remove the seat (with new tool)
Winterthur Gas & Diesel Ltd.
- 300 - Issue 002 2020-10
