8.6.3 Crosshead - install
Periodicity
Description
Unscheduled
Duration for performing preliminary requirements 0.0 man-hours
Duration for performing the procedure 2.0 man-hours
Duration for performing the requirements after job completion 0.0 man-hours
Personnel
Description Specialization QTY
Engine crew Intermediate AR
Support equipment
Description Part No. CSN QTY
Lifting tool 94324 1
Lifting tools 94337 2
Spur-geared chain block 94017-10-4-3 1
Spur-geared chain block 94017-5-5-4 2
Spur-geared chain block 94017-0.5-5-4 1
Spur-geared chain block 94017-7.5-6-5 1
Lever chain hoist 94016-3.2-5.5 2
Lifting tool 94324 1
Eye bolt 94045-M56 6
Eye bolt 94045-M20 2
Shackle (WLL 8500 kg) 94019L 2
Shackles (WLL 13 500 kg) 94019P 2
Shackle (WLL 12 000 kg) 94019N 1
Sling 94039-057 1
Spur-geared trolley 94015-008 1
Deviation pipe 94117B 1
Deviation pipe 94117C 1
Bracket 94322B 1
Deviation pipe 94319 1
Chain 94325 1
Support 94322A 1 or 2
Support 94322 1
Platform 94144 1
Supplies
Description QTY
Bearing oil A/R
Loctite 243 A/R
X72DF
AA00-3326-00AAA-720A-A
Maintenance Manual Crosshead - install
Winterthur Gas & Diesel Ltd.
- 462 - Issue 002 2020-10
