1.6 Data module codes (illustrated parts data)
This manual is divided into several data modules. Each data module is identified with a unique
data module code, refer to Table 1-4 - Data module codes (illustrated parts data). The structure
of the data module codes is as follows:
•
??##-####-##???-###?-? (structure)
•
AA05-5562-01AAA-941A-A (example).
Tab 1-4 Data module codes (illustrated parts data)
Code Description Length/type Property Example
??
1
Alternative versions/designs of items.
Used when two or more items could be
installed in the engine as alternatives
for the same function (for example tur-
bochargers from different suppliers)
2 alphabetic
characters [A-Z]
sequential,
starts with AA
AA
##
2
Applicability related to cylinder number.
00 = applicable to all engines inde-
pendent of the number of cylinders;
## = applicable only to engines with
that specific number of cylinders.
2 numeric char-
acters [0-9]
arbitrary 05
####
2
WinGD design group number 4 numeric char-
acters [0-9]
arbitrary 5562
##
2
Used for sequential numbering of data
modules.
2 numeric char-
acters [0-9]
sequential,
starts with 01
01
???
1
Used for alternative items differing in
design but not enough to change the
variant code (for example AAA = ISO;
AAB = JIS)
3 alphabetic
characters [A-Z]
sequential,
starts with AAA
AAA
###
2
Shipdex information code. 941 = illus-
trated parts data
3 numeric char-
acters [0-9]
default is 941 941
?
1
Shipdex information code variant.
A = spare part
1 alphabetic
character [A-Z]
default is A A
?
1
Shipdex item location code. A = infor-
mation related to items installed on the
product
1 alphabetic
character [A-D]
Shipdex specif-
ic, default is A
A
1
Placeholder symbol for alphabetic characters.
2
Placeholder symbol for numeric characters.
NOTE: For the full list of available Shipdex information codes and more data about the
Shipdex specification, refer to www.shipdex.org.
