8.7.7 Piston - install
Periodicity
Description
Working hours 36 000
Duration for performing preliminary requirements 0.0 man-hours
Duration for performing the procedure 2.0 man-hours
Duration for performing the requirements after job completion 0.0 man-hours
Personnel
Description Specialization QTY
Engine crew Basic AR
Support equipment
Description Part No. CSN QTY
Installation tool 94342 1
Lifting tool 94209 1
Piston suspension device 94341 1
Distance holder 94230 2
Lifting plate 94342A 4
Supplies
Description QTY
Oil A/R
Spare Parts
Description Part No. CSN QTY
Piston 1
SAFETY PRECAUTIONS
WARNING
Injury Hazard: Before you operate the turning gear, make sure that no personnel are near
the flywheel, or in the engine.
PRELIMINARY OPERATIONS
• None
X72DF
AA00-3403-00AAA-720A-A
Maintenance Manual Piston - install
Winterthur Gas & Diesel Ltd.
- 498 - Issue 002 2020-10
To Next Page
General
