WinGD X62DF User Manual

Fig 8-51 Tools - attach
001
002
003
004
005
006
010
004
005
012
007
008
009
011
003
013
001
014
015
016
00746
011
33 Operate the chain block (001, Figure 8-52) to lift the crosshead pin to approximately
300 mm above the center of the pin holes in the column walls.
34 Attach the two chain blocks (002, 007) to the eye bolts on the guide shoes.
X72DF
AA00-3326-00AAA-520A-A
Maintenance Manual Crosshead - remove
Winterthur Gas & Diesel Ltd.
- 450 - Issue 002 2020-10
