WinGD X62DF User Manual

Fig 11-25 Water separator - view 5
001 002
00449
12 Put the spur-geared chain block (001, Figure 11-25) into the middle hole of the lifting
tool.
13 Move the water separator until it hangs vertical to the spur-geared chain block (001).
13.1 Loosen or tighten the spur-geared chain block (001).
13.2 Loosen or tighten the spur-geared chain block (002).
14 Use the engine room crane to move the water separator to an applicable area.
CLOSE UP
• None
X72DF
AA00-6708-00AAA-520A-A
Maintenance Manual Water separator - remove
Winterthur Gas & Diesel Ltd.
- 663 - Issue 002 2020-10
