Fig 11-24 Water separator - view 4
001
003
002
00448
10 Continue to move out the water separator with the lever chain hoist (001) and the spur-
geared chain block (003) until the water separator is fully out of the casing.
11 Remove the lever chain hoist (001) and the disassembly tool (002).
X72DF
AA00-6708-00AAA-520A-A
Maintenance Manual Water separator - remove
Winterthur Gas & Diesel Ltd.
- 662 - Issue 002 2020-10
