Page #67 background image
10/00
2-53
Phaser 790/DocuColor 2006
005-211
Status Indicator RAPs
Initial Issue
005-211 ADF Power RAP
ADF Motor Power Error
Procedure
Remove the ADF Rear Cover. There is +24 VDC from pin 11 to pin 12 on J811.
YN
Go to Flag 1. Check for an open circuit. If the wires are OK, go to the 001-712 RAP.
Check the fuse on the ADF Control PWB (PL 17.2). If the Fuse is OK, replace the ADF Control
PWB (PL 17.2).
