27.2 MELSECNET/10 Connection (PLC To PLC Network)
27.2.1 System Configuration
27 - 21
25
BAR CODE READER CONNECTION
26
PRINTER CONNECTION
27
CNC CONNECTION
28
MULTI-CHANNEL FUNCTION
29
FA TRANSPARENT FUNCTION
30
MULTIPLE-GT11 CONNECTION FUNCTION
31
GATEWAY FUNCTION INDEX
27.2 MELSECNET/10 Connection (PLC To PLC
Network)
Connectable CNC is MELDAS C6/C64 series.
Select a system configuration suitable for your application.
(1) Connectable network
Connect the GOT to the following network systems as an ordinary station.
• MELSECNET/10 network system (PLC to PLC network) optical loop system
• MELSECNET/10 network system (PLC to PLC network) coaxial bus system
(2) Conventions used in this section
Numbers (e.g. ) of System configuration and connection conditions
correspond to the numbers (e.g. ) of System equipment.
Use these numbers as references when confirming models and applications.
27.2.1 System Configuration
1 System configuration and connection conditions
*1 The overall extension cable length and the length between stations vary depending on the cable type to be used
and the total number of stations.
For details, refer to the following manuals.
MELDAS C6/C64 CONNECTION AND MAINTENANCE MANUAL BNP-B2255
MELDAS C6/C64 NETWORK MANUAL BNP-B2373
Connection conditions
System configuration
Number of GOTs Distance
63
(max.)
*1
31
(max.)
*1
MELSECNET/10
Communication driver
5
1
3
Expansion unit
Optical fiber cable
2
4
6
Expansion unit
Coaxial cable
