Mitsubishi GOT1000 Series User Manual

12.4 PLC Side Setting
12.4.2 Connecting to T3 or T3H
12 - 27
9
CONNECTION TO OMRON PLC
10
CONNECTION TO KEYENCE PLC
11
CONNECTION TO SHARP PLC
12
CONNECTION TO TOSHIBA PLC
13
CONNECTION TO HITACHI PLC
14
CONNECTION TO MATSUSHITA PLC
15
CONNECTION TO YASKAWA PLC
16
CONNECTION TO YOKOGAWA PLC
12.4.2 Connecting to T3 or T3H
Enter the transmission parameters.
*1 Indicates only the transmission speeds that can be specified on the GOT side.
*2 Specify the transmission speed to match the baud rate of the GOT.
For how to set the baud rate of the GOT, refer to the following.
Section 12.3.3 Setting communication interface (Communication settings)
12.4.3 Connecting to model 3000 (S2/S3)
Enter the transmission parameters.
*3 Can be used as RS-422.
*4 Indicates only the transmission speeds that can be specified on the GOT side.
*5 Specify the transmission speed to match the baud rate of the GOT.
For how to set the baud rate of the GOT, refer to the following.
Section 12.3.3 Setting communication interface (Communication settings)
Item Setting
Transmission speed
*1*2
4800bps, 9600bps, 19200bps
Data length 7bit
Stop bit 2bit
Parity bit Even
Station No. 1
Item Setting
Transmission method
RS485
*3
RS485 COM1
Timeout time 5 Sec
Transmission speed
*4*5
4800bps, 9600bps, 19200bps
Data length 7bit
Stop bit 2bit
Parity bit Even
Station No. 1
