Mitsubishi GOT1000 Series User Manual

9.2 Connection Cable
9 - 17
9
CONNECTION TO OMRON PLC
10
CONNECTION TO KEYENCE PLC
11
CONNECTION TO SHARP PLC
12
CONNECTION TO TOSHIBA PLC
13
CONNECTION TO HITACHI PLC
14
CONNECTION TO MATSUSHITA PLC
15
CONNECTION TO YASKAWA PLC
16
CONNECTION TO YOKOGAWA PLC
9.2 Connection Cable
The RS-232 cable or RS-422 cable used for connecting the GOT to the PLC should be prepared by the user.
The following provides connection diagrams for each cable, connector specifications and other information.
Model
Connection cable
RS-232 cable
(See Section 9.2.1)
RS-422 cable
(See Section 9.2.2)
PLC CPU
CPM2A
RS-232 cable 1)
CQM1, CCQM1H
CJ1
C200H
CS1
CV500, CV1000, CV2000, CVM1 RS-422 cable 1)
RS-232C adapter CPM1-CIF01, CPM2C-CIF01-V1 RS-232 cable 1)
connection cable
CQM1-CIF01 RS-232 cable 2)
CQM1-CIF02
RS-232 cable 1)
CPM2C-CN111
Rack type host link unit
C200H-LK201-V1 RS-232 cable 3)
C200H-LK202-V1
RS-422 cable 2)
C500H-LK201-V1 RS-232 cable 3)
Serial communication unit
CJ1W-SCU41
RS-232 cable 1)
RS-422 cable 1)
CS1W-SCU21
CJ1W-SCU21-V1
Communication board
C200HW-COM02 RS-232 cable 1)
C200HW-COM03 RS-422 cable 2)
C200HW-COM05
RS-232 cable 1)
C200HW-COM06 RS-422 cable 2)
Serial communication board
CQM1-SCB41
RS-232 cable 1)
RS-422 cable 1)
CS1W-SCB21
CS1W-SCB41 RS-422 cable 1)
