18.1 System Configuration
18.1.2 Connecting to a SIMATIC S7-200 Series
18.1.2 Connecting to a SIMATIC S7-200 Series
1 System configurations and connection conditions
2 System equipment
(1) GOT
(2)
(3) PLC
is a product manufactured by SIEMENS. For details of this product, contact SIEMENS.
Connection condition
System configuration
Number of
GOTs
Distance
1 15m or less
Image No. Name Model name
RS-232 interface
• For RS-232 communication
(Built into GOT)
RS-232 Communication Unit
• For RS-232 communication
GT15-RS2-9P
Image No. Name Model name
PC/PPI cable 6ES7 901-3BF20-0XA0
SIEMENS S7-200
Com municatio n driver
Adapter
2
1
RS-232
RS-232
RS-232
