Mitsubishi GOT1000 Series User Manual

9 - 52
9.4 PLC Side Setting
9.4.8 Connecting serial communication board (CS1W-SCB21, CS1W-SCB41)
9.4.8 Connecting serial communication board (CS1W-SCB21, CS1W-
SCB41)
1 Device settings
Write the following set values to devices of each PLC CPU and initialize each port using a peripheral
tool or DM monitor.
*1 Only transmission speeds available on the GOT side are shown.
*2 Set the same transmission speed as that of the GOT side.
For the transmission speed setting on the GOT side, refer to the following.
Section 9.3.3 Setting communication interface (Communication settings)
*3 Set the host link station No. according to the Host Address setting on the GOT side.
For the Host Address setting on the GOT side, refer to the following.
Section 9.3.3 Setting communication interface (Communication settings)
Device name
Setting
Port 1 Port 2
D32000 D32010
8000H (fixed): The settings are:
Port setting : Arbitrary setting
Serial communication mode : Host link
Start bit : 1 bit
Data length : 7 bits
Stop bit : 2 bits
Parity : Even
D32001 D32011
D32002 D32012 8000H (fixed)
D32003
*3
D32013
*3
0000H to 0001FH
b15 b8 b7 b0
1) Transmission speed
*1*2
00H: 9600bps 08H: 38400bps
05
H: 4800bps 09H: 57600bps
06
H: 9600bps 0AH: 115200bps
07
H: 19200bps
0H
1)
