Mitsubishi GOT1000 Series User Manual

15 - 10
15.1 System Configuration
15.1.5 Connecting to CP-9200SH
15.1.5 Connecting to CP-9200SH
1 System configuration and connection conditions
2 System equipment
(1) GOT
(2) PLC
is a product manufactured by YASKAWA. For details of this product, contact YASKAWA.
Connection conditions
System configuration
No. of GOTs Distance
1
Differs according to
PLC side
specifications.
Image No. Name Model name
RS-232 interface
• For RS-232 communication
(Built into GOT)
RS-232 Communication Unit
• For RS-232 communication
GT15-RS2-9P
Image No. Name Model name
MEMOBUS module CP-217IF
YASKAWA GL/CP9200(SH/H)/CP9300MS
Communication driver
RS-232 cable 3)
3
MEMOBUS module (CN1 connection
)
2
1
RS-232 cable 5)
4
MEMOBUS module (CN2 connection
)
2
1
RS-232
RS-232
RS-232
