Mitsubishi GOT1000 Series User Manual

12 - 26
12.4 PLC Side Setting
12.4.1 Connecting to T2 (PU224), T2E or T2N
12.4 PLC Side Setting
TOSHIBA PLC
For details of the TOSHIBA PLC, refer to the following manual.
User's Manual for the TOSHIBA PLC
12.4.1 Connecting to T2 (PU224), T2E or T2N
1 Switch setting
Configure the switches.
(1) Operation mode setting switch
(2) DIP switch on module PCB (T2N only)
*1 Can be used as RS-422.
2 Transmission parameter setting
Enter the transmission parameters.
*2 Indicates only the transmission speeds that can be specified on the GOT side.
*3 Fixed to 9600bps for T2E only
*4 Specify the transmission speed to match the baud rate of the GOT.
For how to set the baud rate of the GOT, refer to the following.
Section 12.3.3 Setting communication interface (Communication settings)
Model name Refer to
PLC CPU
T2 (PU224), T2E, T2N Section 12.4.1
T3, T3H Section 12.4.2
model 3000 (S2), model 3000 (S3) Section 12.4.3
Switch No. Setting Set data
4OFF (fixed)
Computer link
5OFF (fixed)
Switch No.
Setting
For RS-232 communication For RS-422 communication
DIP switch: No. 1 ON (RS-232C)
OFF (RS-485
*1
)
Item
Setting
Transmission speed
*2*3*4
4800bps, 9600bps, 19200bps
Data length 7bit
Stop bit 2bit
Parity bit Even
Station No. 1
1
2
3
4
5
6
OFF ON
