Mitsubishi GOT1000 Series User Manual

14.4 PLC Side Setting
14 - 35
9
CONNECTION TO OMRON PLC
10
CONNECTION TO KEYENCE PLC
11
CONNECTION TO SHARP PLC
12
CONNECTION TO TOSHIBA PLC
13
CONNECTION TO HITACHI PLC
14
CONNECTION TO MATSUSHITAI PLC
15
CONNECTION TO YASKAWA PLC
16
CONNECTION TO YOKOGAWA PLC
14.4 PLC Side Setting
MATSUSHITA PLC
For details of the MATSUSHITA PLC, refer to the following manual.
User's Manual for the MATSUSHITA PLC.
1 Connecting to the tool port of the PLC CPU
*1 Indicates only the transmission speeds that can be set on the GOT side.
*2 Set the same transmission speed of the GOT.
For the transmission speed setting of the GOT, refer to the following.
Section 14.3.3 Setting communication interface (Communication settings)
*3 The setting range varies with the connected PLC.
2 Connecting to the RS232C and COM port of the PLC CPU
*4 Indicates only the transmission speeds that can be set on the GOT side.
*5 Set the same transmission speed of the GOT.
For the transmission speed setting of the GOT, refer to the following.
Section 14.3.3 Setting communication interface (Communication settings)
*6 The setting range varies with the connected PLC.
*7 Set when connecting to FP0, FP1, FP2 or FP-M.
Item Setting
Transmission speed
*1*2*3
4800bps, 9600bps, 19200bps, 38400bps, 115200bps
Data length 8bit
Stop bit 1bit
Parity bit Odd
Modem connection No
Module No. 1
Item Setting
Transmission speed
*4*5*6
4800bps, 9600bps, 19200bps, 38400bps, 115200bps
Data length 8bit
Stop bit 1bit
Parity bit Odd
Modem connection No
Serial port action selection
*7
1 (Computer link)
Module No. 1
