Mitsubishi GOT1000 Series User Manual

21.1 System Configuration
21.1.4 Connecting to SDC30/31
21 - 9
17
CONNECTION TO ALLEN-BRADLEY PLC
18
CONNECTION TO SIEMENS PLC
19
MICROCOMPUTER CONNECTION
20
CONNECTION TO OMRON TEMPERATURE CONTROLLER
21
CONNECTION TO YAMATAKE TEMPERATURE CONTROLLER
22
CONNECTION TO RKC TEMPERATURE CONTROLLER
23
CONNECTION TO FREQROL SERIES INVERTER
24
SERVO AMPLIFIER CONNECTION
21.1.4 Connecting to SDC30/31
1 System configuration and connection conditions
Connection conditions
System configuration
Number of
GOTs
Number of
temperature
controller
connection
Communi
-cation
Distance
1
1 RS-232 15m or less
31 (max.) RS-485 500m or less
1 31 (max.) RS-485 500m or less
1 31 (max.) RS-485 500m or less
YAMATAKE SDC/DMC
Communication driver
MAX15m
4
RS-232 cable 1)
5
RS-485 cable 2)
6
1
31 (max.)
Interface converter
MAX500m
RS-485 cable 4)
7
2
31 (max.)
MAX500m
RS-485 cable 5)
8
3
31 (max.)
MAX500m
