Mitsubishi GOT1000 Series User Manual

2 - 1
2
1
OVERVIEW
2
BUS CONNECTION
3
DIRECT CONNECTION TO CPU
4
COMPUTER LINK CONNECTION
5
MELSECNET/10 CONNECTION (PLC TO PLC NETWORK)
6
CC-Link CONNECTION (INTELLIGENT DEVICE STATION)
7
CC-Link CONNECTION (Via G4)
8
ETHERNET CONNECTION
BUS CONNECTION
2.1 System Configuration . . . . . . . . . . page 2-2
This section describes the equipment and cables needed
for bus connection.
Select a system suitable for your application.
2.2 Preparatory Procedures for Monitoring
. . . . . . . . . . . . . . . . . . . . . . . . . . page 2-26
This section describes the procedures to be followed
before monitoring in bus connection.
The procedures are written on the step-by-step basis so
that even a novice GOT user can follow them to start
communications.
2.3 Precautions . . . . . . . . . . . . . . . . . page 2-44
This section provides the precautions on bus connection.
Be sure to read this when establishing a bus connection.
2.4 Communication Check Sheet . . . page 2-51
The items to be checked before actual communication by
bus connection can be written down to the check sheet.
