Mitsubishi GOT1000 Series User Manual

6 - 2
6.1 System Configuration
6.1 System Configuration
Select a system configuration suitable for your application.
Conventions used in this section
Numbers (e.g. ) of System configuration and connection conditions correspond
to the numbers (e.g. ) of System equipment.
Use these numbers as references when confirming models and applications.
1 System configuration and connection conditions
*1 Max. overall cable length and the length between stations vary depending on the cable type to be used and
transmission speed.
For details, refer to the following manuals.
• CC-Link System Master/Local Module User’s Manual QJ61BT11N
• Control & Communication Link System Master/Local Module type AJ61QBT11/A1SJ61QBT11 User’s
Manual
• Control & Communication Link System Master/Local Module type AJ61BT11/A1SJ61BT11 User’s Man-
ual
Connection condition
System configuration
Number of
GOTs
Distance
26 (max.) *1
CC-Link (ID)
Communication driver
CC-Link dedicated cable
3
CC-Link module
2
1
