4.2 Connection Cable
4 - 17
1
OVERVIEW
2
BUS CONNECTION
3
DIRECT CONNECTION TO CPU
4
COMPUTER LINK CONNECTION
5
MELSECNET/10 CONNECTION (PLC TO PLC NETWORK)
6
CC-Link CONNECTION (INTELLIGENT DEVICE STATION)
7
CC-Link CONNECTION (Via G4)
8
ETHERNET CONNECTION
4.2 Connection Cable
The RS-232 cable or RS-422 cable used for connecting the GOT to the PLC should be prepared by the user.
The following provides connection diagrams for each cable, connector specifications and other information.
Model
Connection cable
RS-232 cable
(See section 4.2.1)
RS-422 cable
(See section 4.2.2)
Serial communication module
(Q Series)
QJ71C24N, QJ71C24 RS-232 cable 1) RS-422 cable
QJ71C24N-R2, QJ71C24-R2 RS-232 cable 1)
QJ71C24N-R4 RS-422 cable
Serial communication module
(QnA Series)
AJ71QC24N, AJ71QC24 RS-232 cable 2) RS-422 cable
AJ71QC24N-R2, AJ71QC24-R2 RS-232 cable 1)
AJ71QC24N-R4, AJ71QC24-R4 RS-422 cable
A1SJ71QC24N, A1SJ71QC24 RS-232 cable 1) RS-422 cable
A1SJ71QC24N-R2, A1SJ71QC24-R2 RS-232 cable 1)
Computer link module
AJ71UC24 RS-232 cable 2) RS-422 cable
A1SJ71UC24-R2,
A1SJ71UC24-PRF, A1SJ71C24-R2,
A1SJ71C24-PRF
RS-232 cable 1)
A1SJ71UC24-R4,
A1SJ71C24-R4
RS-422 cable
A1SCPUC24-R2 RS-232 cable 1)
A2CCPUC24, A2CCPUC24-PRF RS-232 cable 1) RS-422 cable
