9.1 System Configuration
9.1.1 When connecting to CPM1, CPM1A, CPM2A or CPM2C
9.1 System Configuration
Select a system configuration suitable for your application.
Conventions used in this section
Numbers (e.g. ) of System configuration and connection conditions correspond
to the numbers (e.g. ) of System equipment.
Use these numbers as references when confirming models and applications.
9.1.1 When connecting to CPM1, CPM1A, CPM2A or CPM2C
1 System configuration and connection conditions
When connecting to CPM1
Connection conditions
System configuration
No. of GOTs Distance
1 15m or less
When connecting to CPM1A
Connection conditions
System configuration
No. of GOTs Distance
1 15m or less
OMRON SYSMAC
Communication driver
RS-232C adapter
2
MAX15m
RS-232 cable 1)
6
1
RS232C
CIF01
RS-232C adapter
2
MAX15m
RS-232 cable 1)
6
1
RS232C
CIF01
Connection cable
4
MAX15m
RS-232 cable 2)
7
1
