19.5 Message Formats
This section describes the format of messages that can be used in the microcomputer connection.
19.5.1 Data format type and application
1 Data format type and application
Communication is possible using any of the data formats shown below.
(1) Formats 1, 2 (GOT-A900 series microcomputer connection)
This is the same message format as when a microcomputer connection is established with the
GOT-A900 series.
(2) Formats 3 to 6 (A compatible 1C frame)
This is the same message format as when communication is performed using the dedicated
protocol of the A series computer link module.
(3) Formats 7 to 10 (QnA compatible 3C/4C frame)
This is the same message format as when a communication is performed using the MC protocol of
Q/QnA Series serial communication module.
Type Name Description Reference
Format 1
GOT-A900 series microcomputer connection
(format 1)
This format is used when the GOT is connected to the host in a 1:1
connection.
Section
19.5.3
Format 2
GOT-A900 series microcomputer connection
(format 2)
This is the appended format with error code at the error response of
the GOT-A900 series microcomputer connection (format 1).
Type Name Description Reference
Format 3 A compatible 1C frame (format 1) This is the basic format of the dedicated protocols.
Section
19.5.4
Format 4 A compatible 1C frame (format 2)
This is the appended format of the A compatible 1C frame (format 1)
with a block No.
Format 5 A compatible 1C frame (format 3)
This is the enclosed format of the A compatible 1C frame (format 1)
with STX and ETX.
Format 6 A compatible 1C frame (format 4)
This is the appended format of the A compatible 1C frame (format 1)
with CR and LF.
Type Name Description Reference
Format 7 QnA compatible 3C/4C frame (format 1) This is the basic format of the MC protocols.
Section
19.5.5
Format 8 QnA compatible 3C/4C frame (format 2)
This is the appended format of the QnA compatible 3C/4C frame
(format 1) with block No.
Format 9 QnA compatible 3C/4C frame (format 3)
This is the enclosed format of the QnA compatible 3C/4C frame
(format 1) with STX and ETX.
Format 10 QnA compatible 3C/4C frame (format 4)
This is the appended format of the QnA compatible 3C/4C frame
(format 1) with CR and LF.
To Next Page
